American standard channel steel is a hot-rolled structural steel with a C-shaped cross-section, manufactured according to ASTM standards (e.g., A36, A572), featuring an inner flange slope of approximately 16⅔%, and is widely used in building frames, equipment fabrication, and vehicle structures.

Email : iris@txdmetal.com
Phone/Whatsapp : +8615154137725
Addess : Huaiyin District,Jinan City,Shandong,China.

Description

American Standard Channel is a structural steel with a "C"-shaped cross section. It is characterized by strong vertical bearing capacity, high structural strength, connection with other components by bolts or welding, and its lightweight design makes it lighter than "I"-shaped steel with diversified specifications.
American Standard Channel can be divided into hot-rolled channel steel and cold-bent channel steel according to the production process, ordinary, light and heavy according to the cross-sectional shape, and carbon steel, stainless steel and weather-resistant materials according to the material.

Manufactured using precision rolling technology, our automated production line ensures consistent flange thickness (±0.5mm) and straightness tolerance (≤0.2% of length). Equipped with real-time monitoring systems, we achieve high dimensional accuracy and annual output of 300,000+ tons.

Commodity	Steel Channel
Standard	AISI, ASTM, DIN, GB, JIS, SUS
Certification	SGS, BV, etc
Thick	6#, 8#, 10#, 12#, 14#, 16#, 18#, 20#, 22#, 24# or as your requirements
Length	6 M or as customers' request
Surface	Bright, Polished, Turn smooth(Peeled),Brush, Mill, Pickled etc.
Delivery Time	7-15 days after confirming the order
Container Size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
Trade Term	FOB, CIF, CFR
Payment Term	T/T or L/C
Advantage	Attracting Price; High surface quality,clean; Good appearance of whole coil; First-rate service.
MQQ	1 ton
Specifications	Type	Size	Size
	Stainless steel channel	6#, 8#, 10#, 12#, 14#, 16#, 18#, 20#, 22#, 24#	White acid & Hot rolled & Polished & Sandblas
	Stainless steel flat bar	193mm-20020mm	Black & Pickled & Bright
	Stainless steel square bar	Hot rolled: S10-S40mm Cold rolled: S5-S60mm	Hot rolled & Annealed & Pickled
	Stainless steel angle bar	25 * 25 * 2.5 mm - 150 * 150 * 12 mm	White acid & Hot rolled & Polished
	Stainless steel round bar	193mm-14012mm	Black & Pickled & Bright
	Stainless steel hexagon bar	Cold-rolled: S3.0mm-6.0mm Cold-drawn: S6.0mm-55mm Milling:S55mm-180mm	Cold-rolled, bright surface, some need to do heat treatment

PRODUCT DETAIL
U-bar
Dimensions and Sectional Properties
（1）ASTMA6/A6M-14

Designation Designation Bezeichnung (imperial)	Designation Designation Bezeichnung (metric)	Unit Weight (kg/m)	Dimensions Abmessungen (mm)
Designation Designation Bezeichnung (imperial)	Designation Designation Bezeichnung (metric)	G	H	B	tw	t f	d
C 3 x 4.1	C 75 x 6.1*	6,1	76	35	4,3	6,9	38
C 3 x 5	C 75 x 7.4*	7,4	76	37	6,6	6,9	38
C 3 x 6	C 75 x 8.9*	8,9	76	40	9,0	6,9	38
C 4 x 5.4	C 100 x 8*	8,0	102	40	4,7	7,5	66
C 4 x 7.25	C 100 x 10.8*	10,8	102	43	8,2	7,5	60
C 5 x 6.7	C 130 x 10.4*	10,4	127	44	4,8	8,1	83
C 5 x 9	C 130 x 13*	13,0	127	47	8,3	8,1	86
C 6 x 8.2	C 150 x 12.2*	12,2	152	48	5,1	8,7	107
C 6 x 10.5	C 150 x 15.6*	15,6	152	51	8,0	8,7	107
C 6 x 13	C 150 x 19.3*	19,3	152	54	11,1	8,7	105
C 7 x 9.8	C 180 x 14.6*	14,6	178	53	5,3	9,3	130
C 7 x 12.25	C 180 x 18.2*	18,2	178	55	8,0	9,3	130
C 7 x 14.75	C 180 x 22*	22,0	178	58	10,6	9,3	125
C 8 x 11.5	C 200 x 17.1*	17,1	203	57	5,6	9,9	156
C 8 x 13.75	C 200 x 20.5*	20,5	203	59	7,7	9,9	156
C 8 x 18.75	C 200 x 27.9*	27,9	203	64	12,4	9,9	156
C 9 x 13.4	C 230 x 19.9*	19,9	229	61	5,9	10,5	177
C 9 x 15	C 230 x 22*	22,0	229	63	7,2	10,5	177
C 9 x 20	C 230 x 30*	30,0	229	67	11,4	10,5	173
C 10 x 15.3	C 250 x 22.8*	22,8	254	65	6,1	11,1	203
C 10 x 20	C 250 x 30*	30,0	254	69	9,6	11,1	203
C 10 x 25	C 250 x 37*	37,0	254	73	13,4	11,1	203
C 10 x 30	C 250 x 45*	45,0	254	76	17,1	11,1	203
C 12 x 20.7	C 310 x 30.8*	30,8	305	74	7,2	12,7	248
C 12 x 25	C 310 x 37*	37,0	305	77	9,8	12,7	248
C 12 x 30	C 310 x 45*	45,0	305	80	13,0	12,7	248
C 15 x 33.9	C 380 x 50.4*	50,4	381	86	10,2	16,5	308
C 15 x 40	C 380 x 60*	60,0	381	89	13,2	16,5	308
C 15 x 50	C 380 x 74*	74,0	381	94	18,2	16,5	308

MC 6 x 12	MC 150 x 17.9*	17,9	152	63	7,9	9,5	101
MC 6 x 15.1	MC 150 x 22.5*	22,5	152	74	8,0	12,1	89
MC 6 x 15.3	MC 150 x 22.8*	22,8	152	88	8,6	9,8	91,7
MC 6 x 16.3	MC 150 x 24.3*	24,3	152	76	9,5	12,1	88,2
MC 6 x 18	MC 150 x 26.8*	26,8	152	88	9,6	12,1	85,4
MC 7 x 19.1	MC 180 x 28.4*	28,4	178	87	8,9	12,7	110
MC 7 x 22.7	MC 180 x 33.8*	33,8	178	91	12,8	12,7	109
MC 8 x 8.5	MC 200 x 12.6*	12,6	203	47	4,5	7,9	162
MC 8 x 18.7	MC 200 x 27.8*	27,8	203	75	9,0	12,7	140
MC 8 x 20	MC 200 x 29.8*	29,8	203	76	10,2	12,7	136
MC 8 x 21.4	MC 200 x 31.8*	31,8	203	87	9,5	13,3	132
MC 8 x 22.8	MC 200 x 33.9*	33,9	203	88	10,8	13,3	130
MC 9 x 23.9	MC 230 x 35.6*	35,6	229	87	10,2	14,0	158
MC 9 x 25.4	MC 230 x 37.8*	37,8	229	88	11,4	14,0	155
MC 10 x 8.4	MC 250 x 12.5*	12,5	254	38	4,3	7,1	215
MC 10 x 22	MC 250 x 33*	33,0	254	84	7,4	14,6	179
MC 10 x 25	MC 250 x 37*	37,0	254	86	9,7	14,6	186
MC 10 x 28.5	MC 250 x 42.4*	42,4	254	100	10,8	14,6	178
MC 10 x 33.6	MC 250 x 50*	50,0	254	104	14,6	14,6	178
MC 10 x 41.1	MC 250 x 61.2*	61,2	254	110	20,2	14,6	170
MC 12 x 10.6	MC 310 x 15.8*	15,8	305	38	4,8	7,8	262
MC 12 x 31	MC 310 x 46*	46,0	305	93	9,4	17,8	225
MC 12 x 35	MC 310 x 52*	52,0	305	96	11,8	17,8	218
MC 12 x 40	MC 310 x 60*	60,0	305	98	15,0	17,8	214
MC 12 x 45	MC 310 x 67*	67,0	305	102	18,0	17,8	214
MC 12 x 50	MC 310 x 74*	74,0	305	105	21,2	17,8	222
MC 13 x 31.8	MC 330 x 47.3*	47,3	330	102	9,5	15,5	242
MC 13 x 35	MC 330 x 52*	52,0	330	103	11,4	15,5	242
MC 13 x 40	MC 330 x 60*	60,0	330	106	14,2	15,5	236
MC 13 x 50	MC 330 x 74*	74,0	330	112	20,0	15,5	247
MC 18 x 42.7	MC 460 x 63.5*	63,5	457	100	11,4	15,9	366
MC 18 x 45.8	MC 460 x 68.2*	68,2	457	102	12,7	15,9	370
MC 18 x 51.9	MC 460 x 77.2*	77,2	457	104	15,2	15,9	366
MC 18 x 58	MC 460 x 86*	86,0	457	107	17,8	15,9	375

Product Advantages

1.Channel steel has high strength and stiffness,can withstand large pressure and load, and is widely used in construction, manufacturing and transportation.
2.Channel steel is an economical construction steel with high cost performance and helps to reduce project costs.
3.The material of channel steel makes it have good plasticity and weldability, easy to process and install, and can meet the needs of different shapes and sizes.

American Standard Channel has a wide range of applications and is used in construction and steel structure engineering, including building frames and supporting structures, roof and wall systems, temporary buildings and prefabricated structures; machinery manufacturing and equipment installation, reflected in machinery equipment bases and brackets, vehicles and transportation equipment, and agricultural and engineering machinery; bridges and transportation infrastructure, including bridge auxiliary structures, road facilities; cable trays and brackets and communication towers and signal bases in power and communication engineering; as well as furniture manufacturing and industrial style decoration, and other special applications such as shipbuilding and marine engineering and mining and energy equipment.

In order to ensure product quality, we will arrange professional personnel to check product quality, packaging, weight, hardness, etc., according to customer requirements of product specifications, looking for high-quality and cheap cooperative factories in China, to provide customers with one-stop procurement services and quality assurance.

Excellent packaging: Bundled with steel straps + waterproof wrapping，can effectively protect products from corrosion and various climate changes during transportation. Generally speaking, we ship from Shanghai, Tianjin, Qingdao and Ningbo ports. We have worked with many experienced shipping companies for a long time to find the most suitable mode of transportation for you.
